D372B2
I.CH
37mm DC Gear Motor
Description
For 37mm DC gear motor, the solution that I.CH adopts is the unification of DC motor and spur gearbox. What remarkable feature is that The sophisticated design can result in high efficiency and low noise.
If you have special needs, we can provide custom service.
Advantage
1, Plastic or metal gear can choose
2, Easy to install
3, Offer constant velocity ratio
Gearbox Specifications
Number of Stages | 2 | 3 | 4 | 5 | 6 | 7 |
Reduction Ratio | 10 | 20 | 50 | 150 | 300 | 750 |
30 | 60 | 180 | 350 | 900 | ||
70 | 210 | 450 | 1050 | |||
90 | 270 | 630 | 1350 | |||
Length of Gearbox (mm) | 19.0 | 21.5 | 24.0 | 26.5 | 29.0 | 31.5 |
DC Motor + Gearbox Specifications
Model | Rated Voltage (V) | Rated Torque (kg.cm) | Rated Speed (rpm) | Rated Current (mA) | Output Power (mW) | Torque at Stall (Kg.cm) | Current at Stall (mA) | No Load Speed (rpm) | No Load Current (mA) |
D372-005010 | 24.0 | 0.5 | 660 | 250 | 3500 | 3.0 | 600 | 780 | 50 |
D372-080270 | 24.0 | 8.0 | 18 | 150 | 1500 | 60.0 | 800 | 20 | 50 |
D372-050270 | 24.0 | 5.0 | 10 | 80 | 500 | 40.0 | 500 | 11 | 40 |
D372-090150 | 24.0 | 9.0 | 25 | 190 | 2300 | 28.0 | 700 | 32 | 50 |
D372-010030 | 24.0 | 1.0 | 145 | 110 | 1500 | 9.0 | 700 | 165 | 50 |
D372-020030 | 12.0 | 2.0 | 150 | 400 | 3100 | 8.0 | 1500 | 195 | 80 |
D372-040090 | 12.0 | 4.0 | 52 | 400 | 3100 | 22.0 | 1500 | 65 | 70 |
D372-090150 | 12.0 | 9.0 | 30 | 400 | 2700 | 25.0 | 1500 | 40 | 70 |
D372-030070 | 12.0 | 3.0 | 82 | 400 | 2500 | 18.0 | 1900 | 100 | 90 |
* Specification can be customized as the inquiry. Contact: sales@ichmo.com
