S593
I.CH
59mm AC Synchronous Motor
Description
Powerful high torque.Specially designed for Electric equipment, Laminator HVAC system,CATV-system.
Excellent durable quality. Comfort quiet running, with no vabration.
Specification
| Model | Output speed (rpm) | Output Torque (kg.cm / lb.in) | Voltage (V.AC) | Current (A) | Frequency (Hz) | Input Power (W) | Noise (dB) | Rotation | ||
| S1 continuous | S2 15 minutes | S2 5 minutes | ||||||||
| S593-50-3 | 2.5 | 50 / 43.5 | 80 / 69.6 | 100 / 87 | 24 ********* 110 ********* 220 | <0.3 ********** <0.065 ********* <0.032 | 50/60Hz | <16 | <45 | CW / CCW / Bi-directional |
| S593-50-5 | 5 | 50 / 43.5 | 80 / 69.6 | 100 / 87 | ||||||
| S593-25-10 | 10 | 25 / 21.8 | 45 / 39.2 | 52 / 45.2 | ||||||
| S593-20-12 | 12 | 20 / 17.4 | 37 / 32.2 | 43 / 37.4 | ||||||
| S593-16-15 | 15 | 16 / 13.9 | 29 / 43.5 | 35 / 30.5 | ||||||
| S593-12-20 | 20 | 12 / 10.4 | 22 / 19.1 | 26 / 22.6 | ||||||
| S593-8-30 | 30 | 8 / 7 | 15 / 13 | 17.5 / 15.2 | ||||||
| S593-4-60 | 60 | 4 / 3.5 | 7 / 6 | 8.8 / 7.7 | ||||||
| S593-3-98 | 98 | 2.5 / 2.18 | 4.5 / 3.9 | 5.3 / 4.6 | ||||||
| Note: Above datas are from motors under 50Hz. If under 60Hz, Speed*1.2 , Torque/1.2 Other speed and torque needed, please contact our sale department | ||||||||||
Safety
| Insulation resistance | DC 500V 100M ohms |
| Insulation strength | AC1500V, 50Hz/min(220V motor) |
| Insulation class | E(105℃) / B(130℃) |
| Environment | Temp.-10℃~+40℃ / Humidity: <85 |
| Certification | CE ROHS CCC |
Description
Powerful high torque.Specially designed for Electric equipment, Laminator HVAC system,CATV-system.
Excellent durable quality. Comfort quiet running, with no vabration.
Specification
| Model | Output speed (rpm) | Output Torque (kg.cm / lb.in) | Voltage (V.AC) | Current (A) | Frequency (Hz) | Input Power (W) | Noise (dB) | Rotation | ||
| S1 continuous | S2 15 minutes | S2 5 minutes | ||||||||
| S593-50-3 | 2.5 | 50 / 43.5 | 80 / 69.6 | 100 / 87 | 24 ********* 110 ********* 220 | <0.3 ********** <0.065 ********* <0.032 | 50/60Hz | <16 | <45 | CW / CCW / Bi-directional |
| S593-50-5 | 5 | 50 / 43.5 | 80 / 69.6 | 100 / 87 | ||||||
| S593-25-10 | 10 | 25 / 21.8 | 45 / 39.2 | 52 / 45.2 | ||||||
| S593-20-12 | 12 | 20 / 17.4 | 37 / 32.2 | 43 / 37.4 | ||||||
| S593-16-15 | 15 | 16 / 13.9 | 29 / 43.5 | 35 / 30.5 | ||||||
| S593-12-20 | 20 | 12 / 10.4 | 22 / 19.1 | 26 / 22.6 | ||||||
| S593-8-30 | 30 | 8 / 7 | 15 / 13 | 17.5 / 15.2 | ||||||
| S593-4-60 | 60 | 4 / 3.5 | 7 / 6 | 8.8 / 7.7 | ||||||
| S593-3-98 | 98 | 2.5 / 2.18 | 4.5 / 3.9 | 5.3 / 4.6 | ||||||
| Note: Above datas are from motors under 50Hz. If under 60Hz, Speed*1.2 , Torque/1.2 Other speed and torque needed, please contact our sale department | ||||||||||
Safety
| Insulation resistance | DC 500V 100M ohms |
| Insulation strength | AC1500V, 50Hz/min(220V motor) |
| Insulation class | E(105℃) / B(130℃) |
| Environment | Temp.-10℃~+40℃ / Humidity: <85 |
| Certification | CE ROHS CCC |
| Mechanical Dimensions |
 |
| Mechanical Dimensions |
|
Custom Shaft
Round Shaft， D-Cut Sahft， H-Cut Shaft， Custom Length
Custom Shaft
Round Shaft， D-Cut Sahft， H-Cut Shaft， Custom Length
Factory Ability
I.CH concentrates on designing the latest technology motors and meet our customers requirements, we have the very capable R&D team to ensure products quality, and provide all the customers with best solution, now the products like AC Synchronous Motor, Geared Motor, Reversible Synchronous Motor widely used in household appliance, Auto Control Machine, etc.
Advantages
1. Reliable supplier, direct manufacture 8 years;
2. CE, ROHS, IS09001... Certificate report;
3. OEM&OED Service, after-sales service 24*7, technical support;
Package
-Wrap the goods in a rigid way;
-Shipping way: Sea, air or train;
-Lead time: 15 - 40 working days.
FAQ
Q: What lowest speed can you make?
A: 1 rpm to 2rpm..
Q: What application of your AC reversible synchronous motor?
A: household appliance, Auto Control Machine, etc.
Q: If I place an order, how long will you ship out the goods?
A: For the sample order, it takes approximate 2 weeks; for the batch order, lead time will be around 40 days.
Q: Do you provide OEM services?
A: Yes, we can provide OEM services for volume production. Feel free to talk to us about your branding needs.
Factory Ability
I.CH concentrates on designing the latest technology motors and meet our customers requirements, we have the very capable R&D team to ensure products quality, and provide all the customers with best solution, now the products like AC Synchronous Motor, Geared Motor, Reversible Synchronous Motor widely used in household appliance, Auto Control Machine, etc.
Advantages
1. Reliable supplier, direct manufacture 8 years;
2. CE, ROHS, IS09001... Certificate report;
3. OEM&OED Service, after-sales service 24*7, technical support;
Package
-Wrap the goods in a rigid way;
-Shipping way: Sea, air or train;
-Lead time: 15 - 40 working days.
FAQ
Q: What lowest speed can you make?
A: 1 rpm to 2rpm..
Q: What application of your AC reversible synchronous motor?
A: household appliance, Auto Control Machine, etc.
Q: If I place an order, how long will you ship out the goods?
A: For the sample order, it takes approximate 2 weeks; for the batch order, lead time will be around 40 days.
Q: Do you provide OEM services?
A: Yes, we can provide OEM services for volume production. Feel free to talk to us about your branding needs.
